$3.85 – $5.23
Straight Female threaded Pushfit connector Metric OD Tube
Model: PCF
Pisco Pneumatic Straight Female push-in fittings of your selected sizing.
To enable offering a complete range of sizes/combinations with continuous stock availability we stock Pisco as our primary range. However, in certain configurations or at times of lower supply availability we do substitute in other brands of fittings. This includes upgrading to brass if required.
| Weight | N/A |
|---|---|
| Dimensions | N/A |
| Tube Size | 4mm OD tube, 6mm OD tube, 8mm OD tube, 10mm OD tube, 1/4 (6.35mm) OD tube |
| Thread | 1/8 BSPP (9.73mm OD), 1/8 NPT (10.3mm OD), 1/4 BSPP (13.1mm OD), 3/8 BSPP (16.6mm OD), 3/8 NPT (17mm OD) |
Fluid Admitted: Air, Water (Conditional)
Remarks: For water: Surge pressure must be lower than max service pressure and use of insert ring
Service Pressure Range at 20ºC: 0~150 psi (0~1MPa)
Service Temperature Range: 32~140ºF (0~60ºC)
Working Vacuum: -29.5in.Hg (-100kPa)
PISCO_Straight_Female_DATASHEET – CLICK HERE TO DOWNLOAD
